Parameters

Specifications

Unit

4CH

12CH

Operating Wavelength

1260-1360

nm

Channel Wavelength

1269.23/1273.54/1277.89/

1282.26/1286.66/1291.10/

1295.56/1300.05/1304.58/

1309.14/1313.73/1318.35

nm

Channel Spacing

800

GHz

Insertion Loss¹

≤1.8

≤3.2

dB

Isolation

Adjacent

≥30

dB

Non-adjacent

≥40

dB

Insertion Loss Temperature Sensitivity

≤0.5

dB

Ripple

≤0.5

dB

Wavelength Temperature Shifting

≤0.002

nm/℃

Polarization Dependent Loss

≤0.2

dB

Polarization Mode Dispersion

≤0.1

ps

Directivity

≥50

dB

Return Loss

≥45

dB

Maximum Power Handing

300

mW

Operating Temperature

-10~+70

℃

Storage Temperature

-40~+85

℃

Package size

L80×W58×H8

L120×L80×H18

mm
