Parameter

Unit

Specification

Note

Wavelength Tuning Range

nm

1400 ~ 1700

Passband Width @ -3.0 dB

nm

< 3.0

Passband Width @ -20 dB

nm

≤ 10

Peak Insertion Loss

dB

< 4.5

Without connectors

Polarization Dependent Loss

dB

< 0.7

At CW

Chromatic Dispersion

ps/nm

< ±10

Within CW ± 0.2nm

Polarization Mode Dispersion

ps

< 0.1

Wavelength Tuning Resolution

nm

< 0.04

Wavelength Setting Error

nm

< ±0.1

Wavelength Setting Repeatability

nm

±0.04

Wavelength Temperature Dependence

pm/。C

< ±10

Return Loss

dB

> 40

Maximum Input Optical Power

mW

300

Tuning Speed

s

< 0.5

Channel to channel
