Dense wave division multiplexing uses the wavelength of the laser to transmit data within the fiber in parallel transmission of bitbits or string line transmission. It utilizes thin-film coating technology and the design of proprietary non-flux metal weldmicro optical packaging to achieve the upand and downlines of light within ITU wavelengths. DWDM is an important part of fiber optic network, which allows IP protocol, ATM and synchronous fiber optic network/synchronous digital sequence (SONET/SDH) protocol to carry the e-mail, video, multimedia, data and voice data are transmitted through a unified fiber layer.

Order information

DWDM Module PN:DWDMM_XXXXXXXXXX-XX(DWDMM+10 Code+2Serial Number )

Specifications

Parameters		Specifications			Unit
		4CH	8CH	16CH
Operating Wavelength		1460-1620			nm
Channel Wavelength		ITU Grid			nm
Channel Spacing		100/200			GHz
Channel Passband(@-0.5dB bandwidth)		≥0.3			nm
Insertion Loss¹		≤1.8	≤3.0	≤3.5 ≤5.0	dB
Isolation	Adjacent	≥30			dB
	Non-adjacent	≥40			dB
Insertion Loss Temperature Sensitivity		≤0.5			dB
Ripple		≤0.5			dB
Wavelength Temperature Shifting		≤0.002			nm/℃
Polarization Dependent Loss		≤0.2			dB
Polarization Mode Dispersion		≤0.1			ps
Directivity		≥50			dB
Return Loss		≥45			dB
Maximum Power Handing		300			mW
Operating Temperature		-10~+70			℃
Storage Temperature		-40~+85			℃
Package size		L100×L80×H10		L120×L80×H18	mm
