The coarse wave divider (CWDM) is the use of optical multiplexer to multiplex the optical signal of different wavelengths to a single fiber for transmission, in the receiving end of the link, with the help of the optical solution multiplexer to break down the mixed signal in the fiber into different wavelengths of signal, connected to the corresponding receiving device. It can save fiber resources and network ingmon costs, and it solves the problems of fiber shortage and multi-service transparent transmission.

Order information

CWDM ModulePN:CWDMM-XOxxXX(CWDMM+9 Code+2 Serial Number)

Specifications

Parameters		Specifications			Unit
		4CH	8CH	16CH
Operating Wavelength		1260-1620			nm
Channel Wavelength		1270~16101271~1611			nm
Channel Spacing		20			nm
Channel Passband(@-0.5dB bandwidth)		≥13			nm
Insertion Loss¹		≤1.5	≤2.5	≤3.5 ≤4.5	dB
Isolation	Adjacent	≥30			dB
	Non-adjacent	≥40			dB
Insertion Loss Temperature Sensitivity		≤0.5			dB
Ripple		≤0.5			dB
Wavelength Temperature Shifting		≤0.002			nm/℃
Polarization Dependent Loss		≤0.2			dB
Polarization Mode Dispersion		≤0.1			ps
Directivity		≥50			dB
Return Loss		≥45			dB
Maximum Power Handing		300			mW
Operating Temperature		-10~+70			℃
Storage Temperature		-40~+85			℃
Package size		L100×L80×H10		L120×L80×H18	mm
