Parameters |
Unit |
Specifications |
|
Operating Wavelength |
nm |
1310/1480 or 1550 |
|
Operating Wavelength Range |
nm |
±40 |
|
Insertion Loss1 |
dB |
≤0.7 |
|
Extinction Ratio (for splitter only) |
dB |
≥18 |
|
Return Loss |
dB |
≥50 |
|
Directivity |
dB |
≥50 |
|
Package dimensions |
mm |
5.5*35 |
|
Fiber Type |
- |
PM Panda fiber |
|
Fiber Length |
mm |
1000(+100/-0) |
|
Max Optical Power |
mW |
500 |
|
Operating Temperature |
℃ |
-40~+85 |
|
Storage Temperature |
℃ |
-40~+85 |
|
Connector Type |
- |
N/A |
|
Connector key aligned |
- |
N/A |
|
Working shaft |
- |
N/A |
|
Key angle to PM axis |
degree |
N/A |
