Hirundo's mechanical optical switch has the advantages of low insertion loss and small size, and is the ideal device for dynamic configuration of the plug-in multiplexer OADM, cross- connector OXC, system monitoring and protection, and the small package is easier to integrate into the high density optical communication system, with locking and non-locking control types.

Order information

SW (Switch) PN: SWXXXXXXX-Xx(SW+11 Code+2 Serial Number)

Specifications

Specifications
Parameter	Unit	Value
Operating Wavelength Range	nm	1530 - 1570/1570 - 1610
Insertion Loss	dB	≤ 0.8
Attenuation Range	dB	> 30
Block State (Dark type, IL at power off)	dB	> 40
Polarization Dependence Loss @ 0 dB	dB	≤ 0.1
Polarization Dependence Loss @ 20 dB	dB	≤ 0.3
Min. Extinction Ratio	dB	18
Wavelength Dependence Loss @ 10 dB	dB	≤ 0.5
Wavelength Dependence Loss @ 20 dB	dB	≤ 1.0
Return Loss	dB	> 45
Response Time	ms	≤ 2
Max. Optical Power (Continuous Wave)	mW	300
Drive Voltage	V	≤ 8
Fiber Type	-	PM 1550 /1310Fiber；special
Operating Temperature	℃	- 5 to + 70
Storage Temperature	℃	- 40 to + 85
