Specifications

Parameter

Unit

Value

Operating Wavelength Range

nm

1530 - 1570/1570 - 1610

Insertion Loss

dB

≤ 0.8

Attenuation Range

dB

> 30

Block State (Dark type, IL at power off)

dB

> 40

Polarization Dependence Loss @ 0 dB

dB

≤ 0.1

Polarization Dependence Loss @ 20 dB

dB

≤ 0.3

Min. Extinction Ratio

dB

18

Wavelength Dependence Loss @ 10 dB

dB

≤ 0.5

Wavelength Dependence Loss @ 20 dB

dB

≤ 1.0

Return Loss

dB

> 45

Response Time

ms

≤ 2

Max. Optical Power (Continuous Wave)

mW

300

Drive Voltage

V

≤ 8

Fiber Type

-

PM 1550 /1310Fiber；special

Operating Temperature

℃

- 5 to + 70

Storage Temperature

℃

- 40 to + 85
