Parameters |
Specifications |
Unit |
||||
|
Channel |
1＜N≤12 |
16＜N≤32 |
32＜N≤64 |
64＜N≤128 |
|
|
|
Insertion Loss1 |
≤1.0 |
≤1.0 |
≤1.5 |
≤2.0 |
dB |
|
|
Wavelength Range |
850±40 or 1260-1650 |
nm |
||||
|
Testing Wavelength |
850 or 1310/1550 |
nm |
||||
|
Crosstalk |
MM≥35 SM≥55 |
dB |
||||
|
Return Loss |
MM≥30 SM≥50 |
dB |
||||
|
Polarization Dependent Loss |
≤0.05 |
dB |
||||
|
Wavelength Dependent Loss |
≤0.25 |
dB |
||||
|
Temperature Dependent Loss |
≤0.25 |
dB |
||||
|
Repeatability |
≤0.02 |
dB |
||||
|
Power Supply |
5 or 12 |
V |
||||
|
Lifetime |
≥107 |
Times |
||||
|
Switch Time |
≤8 |
ms |
||||
|
Power Supply |
500 |
mW |
||||
|
Operation Temperature |
-20 ~ +70 |
℃ |
||||
|
Storage Temperature |
-40 ~ +85 |
℃ |
||||
|
Package Dimension |
1＜N≤12（135×64×32） |
12＜N≤16（184×78×36） |
16＜N≤32（140×77.5×64） |
31＜N≤88（184×156×66） |
88＜N≤128（184×220×66） |
mm |
