Parameter

Symbol

Min

Typ

Max

Unit

NOTE

Main Supply Voltage

Vcc5

4.75

5.25

V

Supply Voltage #2

Vcc3

3.13

3.45

V

Supply Current-Vcc5 supply

Icc5

350

mA

Supply Current-Vcc3 supply

Icc3

450

mA

Module total power

P

3.5

W

1

Transmitter

Input differential impedance

Rin

100

Q

2

Differential data input swing

Vin,pp

120

820

mV

Transmit Disable Voltage

VD

2.0

Vcc

V

3

Transmit Enable Voltage

VEN

GND

GND+0.8

V

Transmit Disable Assert Time

10

us

Receiver

Differential data output swing

Vout,pp

340

650

850

mV

4

Data output rise time

tr

38

ps

5

Data output fall time

tf

38

ps

5

LOS Fault

VLoS fault

Vcc-0.5

VccHOST

V

6

LOS Normal

VLOS norm

GND

GND+0.5

V

6

Power Supply Rejection

PSR

See Note 6 below

7
