Parameters

Specifications

Unit

Grade P

Grade A

Directivity

Port 1 to Port 2 to Port 3

-

Center Wavelength(λc)

1310 or 1550

nm

Operating Wavelength Range

λc±30

nm

Typical Peak Isolation

≥50

dB

Min Isolation @23℃, full wavelength

≥40

dB

Typical Insertion Loss@23℃

≤0.6

≤0.8

dB

Insertion Loss

≤0.8

≤1.0

dB

Crosstalk

≥50

dB

Return Loss

≥50

dB

Polarization Mode Dispersion

≤0.1

ps

Polarization Dependent Loss@23℃

≤0.1

dB

Optical Average Power

500 or Customize

mW

Tensile Load

≤5

N

Operating Temperature

-0~+70

℃

Storage Temperature

-40~+85

℃

Fiber Type

SMF-28e or Customize

Fiber Length

1.0 or Customize

m

Connector

Customize

Package size

f5.5 × L50

mm
